Description
Products Description:
1. The electric-driven flat pipe jacking machine is mainly suitable for ordinary soil layers and sand layers, and has high construction efficiency especially in silt and quicksand strata.
2. The excavation surface has good support effect, small ground settlement, and controllable surface deformation.
3. The cutter head speed, jacking speed, and mud flow rate can be adjusted steplessly, and the equipment has good controllability. 4. Human-computer interactive console dynamically displays the operating parameters and working status of each component.
PRODUCT PARAMETER
| Model | Cutterhead power (kW) | Maximum speed of cutterhead ( r/min) | Cutterhead power(t) | Mud inlet and discharge pipe diameter(mm) | Outer diameter × length (mm） |
| XDN800-S | 30×1 | 5.7 | 63×3 | 100 | φ980×3000 |
| XDN1000-S | 30×1 | 5.7 | 63×3 | 100 | φ1220×3000 |
| XDN1200-S | 22×2 | 4.4 | 63×4 | 100 | φ1460×4150 |
| XDN1350-S | 22×2 | 4.4 | 63×4 | 100 | φ1640×4150 |
| XDN1400-S | 22×2 | 4.4 | 63×4 | 100 | φ1700×4150 |
| XDN1500-S | 30×2 | 4.2 | 80×4 | 125 | φ1820×4570 |
| XDN1600-S | 30×2 | 4.2 | 80×4 | 125 | φ1940×4520 |
| XDN1650-S | 30×2 | 4.2 | 80×4 | 125 | φ2000×4520 |
| XDN1800-S | 30×3 | 4.2 | 100×4 | 125 | φ2180×4520 |
| XDN2000-S | 30×3 | 4.2 | 120×4 | 125 | φ2420×4520 |
| XDN2200-S | 30×4 | 3.2 | 150×4 | 150 | φ2670×4935 |
| XDN2400-S | 30×4 | 3.2 | 150×4 | 150 | φ2910×4935 |
| XDN2600-S | 30×5 | 3.2 | 200×4 | 150 | φ3150×4935 |
| XDN2800-S | 30×5 | 3.2 | 200×4 | 150 | φ3390×4935 |
| XDN3000-S | 37×6 | 2.8 | 200×4 | 150 | φ3630×4735 |
| XDN3200-S | 37×6 | 2.8 | 155×8 | 150 | φ3860×4735 |
| XDN3500-S | 37×6 | 2.6 | 200×8 | 150 | φ4130×4900 |
| XDN4000-S | 37×8 | 2.6 | 200×8 | 150 | φ4830×4900 |
